An Introduction to Entropy

Entropy

This and the following posts were inspired by reading Chris Olah's excellent post on visual information theory and also by a Medium post on entropy, that I unfortunately can't remember the name of and so cannot link it here. I found the notion of entropy and cross-entropy quite confusing when I first came across it, so I decided to write something up to bring together different pieces I had learned related to information theory to help clarify things for myself and to share with colleagues at the time.

If you’ve done any work in machine learning, chances are you’ve come across a cross-entropy loss function. Cross-entropy is a powerful concept, drawn from the field of information theory, but it is a bit more complex, and less intuitive - at least for the average human, myself very much included - than something like mean-squared error. It seems to be much more natural for humans to think of difference in terms of Euclidean distance, rather than something like “information loss”, or the distance between probability distributions. This post and the next will attempt to give a brief introduction to entropy, cross-entropy, and a couple of other related ideas that are important in machine learning.

Information theory comes from Claude Shannon, an American mathematician, electrical engineer, and cryptographer who was one of those awe-inspiring geniuses that seem to pop up in the world of mathematics from time to time. Among his many remarkable contributions, Shannon published an article titled “A Mathematical Theory of Communication” in the Bell System Technical Journal in 1948. This article, published in two-parts, introduced the notion of information entropy and laid out the foundation for what would become known as information theory.

What is Entropy?

Given a probability distribution $p(x)$, Entropy is defined as $$Entropy = H(p) = -\sum_{x} p(x)\log_{2}p(x) = E_{x\sim p}[-\log_{2}p(x)]$$

While you might be able to draw out some intuition just by staring at this definition long enough, it’s not exactly clear what entropy is used for, what motivated this definition, nor what it means in a useful sense, so let’s dig into that a little bit.

We’ll start with the motivation. Shannon was looking for ways to send messages efficiently without losing information - given that he worked for Bell labs you can imagine why he would have been interested in this. Shannon measured efficiency in terms of message length, so he wanted to minimze message length while ensuring that there could be no information loss or ambiguity in the message sent.

To make this a little more clear we'll consider an example. Suppose that there are two individuals communicating with each other, call them Josh and Drew. Josh and Drew are big surfing fans and they are constantly communicating with each other regarding surfing conditions. Josh lives right next to the beach, so he sends Drew updates about the surf conditions. Josh likes to keep things simple, so he communicates only two options to Drew: "Good" or "Not Good".

Since we only have two possible messages, and because we are thinking about encoding messages for computers to send, we have a binary situation. The most efficient way to send these messages would be to encode "Good" as 1 and "Not Good" as 0.

$$\begin{equation*} \begin{split} Good = 1 \\ Not\ Good = 0\\ \end{split} \end{equation*}$$

Not only is this encoding the most efficient way for Josh to send his information, but it is also lossless, i.e. it completely preserves information. If Drew recieves a 1 he knows conditions are "Good" and 0 "Not Good". There is no ambiguity no matter how many messages Josh sends.

That's all fine and dandy if Josh only ever sends those two messages, but if he's feeling a little more creative and starts to also send "Great" and "Terrible" to Drew to give him a better idea of what to expect, we'll need to adjust our encoding scheme. Using one bit to encode these messages will no longer be sufficient because we wouldn't be able to distinguish between messages, so we'll need to move to two bits to get a lossless encoding.

$$ \begin{equation*} \begin{split} Great = 00 \\ Good = 01 \\ Not\ Good = 10\\ Terrible = 11 \\ \end{split} \end{equation*} $$

We have again achieved a lossless encoding using two bits to encode each message, but once we move to more than two messages, the question of what the most efficient encoding is gets more complicated. If Josh sends each of the four messages with equal probability, we have indeed found the most efficient encoding (or any permutation of the encoding scheme given), but if the messages are not sent with equal probability, the situation gets more complicated.

Consider the following probability distribution for messages:

This is obviously not a uniform distribution, and it forces us to ask the question as to whether or not using a two bit encoding for each message is the most efficient encoding possible. Given that Josh sends "Great" far more often than any other message, it seems likely that choosing a shorter encoding for "Great" could help us get to a more efficient average message length. What if instead of our original encoding scheme we use the following:

$$\begin{equation*} \begin{split} Great = 0 \\ Good = 01 \\ Not\ Good = 111\\ Terrible = 110 \\ \end{split} \end{equation*}$$

We can actually calculate what the average message encoding length will be under these two schemes. To do this we need an expected value of the encoding length. For a message $x$, the probability of sending that message will be denoted $p(x)$, and the message length will be denoted as $l(x)$.

Scheme 1:

$$\begin{equation*} \begin{split} Average\ length = E(l(x)) &= \sum_{x} p(x)l(x) \\ &= (\frac{3}{4} \cdot 2) + (\frac{1}{8} \cdot 2) + (\frac{1}{16} \cdot 2) + (\frac{1}{16} \cdot 2) \\ &= \frac{12}{8} + \frac{2}{8} + \frac{1}{8} + \frac{1}{8} \\ &= \frac{16}{8} \\ &= 2 \\ \end{split} \end{equation*}$$

Scheme 2:

$$\begin{equation*} \begin{split} Average\ length = E(l(x)) &= \sum_{x} p(x)l(x) \\ &= (\frac{3}{4} \cdot 1) + (\frac{1}{8} \cdot 2) + (\frac{1}{16} \cdot 3) + (\frac{1}{16} \cdot 3) \\ &= \frac{12}{16} + \frac{4}{16} + \frac{3}{16} + \frac{3}{16} \\ &= \frac{22}{16} \\ &= 1.375 \\ \end{split} \end{equation*}$$

So the average message length when we use two bits to encode each message is (obviously) 2, whereas the average message length with our slightly more complex second scheme is 1.375 bits. Thus we have shown that the second scheme is in fact a more efficient encoding than the first scheme.

We can see from this toy example that optimal encoding length depends on the probability distribution over the space of possbile messages. I also have not gone into any kind of detail regarding necessary and sufficient conditions for a lossless encoding. The encoding schemes presented above are in fact lossless, but not every scheme is lossless. For example, the following scheme is not lossless:

$$\begin{equation*} \begin{split} Great = 0 \\ Good = 1 \\ Not\ Good = 00\\ Terrible = 11 \\ \end{split} \end{equation*}$$

The fact that this is not lossless is fairly easy to see. For example, if Josh were to send "$0100$" it is impossible to know if this means "Great, Good, Not Good", or instead "Great, Good, Great, Great". Necessary and sufficient conditions for the existence of a uniquely decodeable code for a given set of codeword lengths are given by the Kraft-McMillan inequality. I wont go into detail or prove the Kraft-McMillan inequality here, but you can refer to its Wikipedia page if you want a more in-depth treatment.

The statement of the Kraft-McMillan inequality, as per Wikipedia, is as follows:

Let each source symbol from the alphabet $$ S = \{s_1, s_2, \ldots, s_n \} $$ be encoded into a uniquely decodable code over an alphabet of size $r$ with codeword lengths $$l_1, l_2, \ldots , l_n. $$ Then $$ \sum_{i=1}^{n}r^{-l_i} \le 1 $$ Conversely, for a given set of natural numbers $l_1, l_2, \ldots , l_n$ satisfying the above inequality, there exists a uniquely decodable code over an alphabet of size $r$ with those codeword lengths.

At this point you could be forgiven if you're asking yourself "What does all this have to do with entropy?", so I will try to make that connection now.

We'll start by taking a look at the Kraft-McMillan inequality and seeing if we can connect that to entropy. Because we are talking about encoding messages in binary, our alphabet is the set $\{0, 1\}$ and so $r=2$. Let's say we have $N$ distinct messages to send, so we have codeword lengths $l_1, l_2, \ldots, l_N$. To simplify things, let's say we have a uniform probability distribution over our message space. That is, we are equally likely to send any one of our $N$ messages. If this is the case then there is no advantage to having different lengths for messages, so let us choose a constant, $\mathcal{L}$, to be our message length.

$$l_i = \mathcal{L},\ \ 1 \le i \le N$$

Now the Kraft-McMillan inequality looks like this: $$\sum_{i=1}^{N} 2^{-\mathcal{L}} = \sum_{i=1}^{N} \frac{1}{2^{\mathcal{L}}} = \frac{N}{2^{\mathcal{L}}} \le 1$$ Now, we can try to solve for $\mathcal{L}$ to find out what kind of constraint we have on the codes for our message lengths. $$\begin{equation*} \begin{split} \frac{N}{2^{\mathcal{L}}} &\le 1 \\ N &\le 2^{\mathcal{L}} \\ \log_2{N} &\le \mathcal{L} \\ \mathcal{L} &\ge \log_2{N} \end{split} \end{equation*}$$ So if we have a constant code length for our messages, it has to be greater than or equal to $\log_2$ of the number of distinct messages that might be sent. Since we are looking for a minimal encoding size, we would want to go with equality. Hence, in the case of equally probable messages, our optimal message length is $$\log_{2}N = \log_{2} \frac{1}{p(x)} = - \log_{2} p(x)$$ Here $p(x)$ is the probability of message $x$ being sent. This is finally starting to look suspiciously similar to our formula for calculating entropy. We can see that here $- \log_{2} p(x)$ in the entropy formula represents the length of the encoding of the message, so calculating the entropy will give us the expected or average message length, just like we calculted earlier in our example with Josh and Drew.

In fact, entropy gives you the most efficient encoding for messages irrespective of the probability distribution over the message space. If we revisit our example from before, we can try to calculate the optimal message lengths based on the probability distribution.

If we calculate the entropy we get $$\begin{split} H(p) &= -\sum p(x)\log_2 p(x) \\ &= -(3/4 \cdot \log_2(3/4) + 1/8 \cdot \log_2(1/8) + 1/16 \cdot \log_2(1/16) + 1/16 \cdot \log_2(1/16)) \\ &= -((-0.31) - 3/8 - 1/4 - 1/4) \\ &= 1.185 \end{split}$$ This is a better average message length than we got with our earlier encoding, but the only problem is that we can't encode messages with fractions of bits, so we'll have to round. We need to use at least one bit to encode "Great", but if it were possible to encode with fractions of bits, the entropy would give us an optimal encoding for our messages.

Given our additional constraint of not being able to encode messages using fractional bits, we can round off our message lengths in order to come up with an encoding scheme.

Since we have to use at least one bit to encode "Great", we are able to actually reduce the length of the encoding for the other messages from our previous example while still satisfying the Kraft-McMillan inequality. $$\begin{split} \sum_{i=1}^{N} 2^{-l_i} &= \sum_{i=1}^{N} \frac{1}{2^{l_i}} \\ &= \frac{1}{2^{1}} + \frac{1}{2^{2}} + \frac{1}{2^{3}} + \frac{1}{2^{3}}\\ &= \frac{1}{2} + \frac{1}{4} + \frac{1}{8} + \frac{1}{8}\\ &= 1 \end{split}$$

This is the same encoding scheme that we presented earlier in the post, and after doing our expected message length (i.e. entropy) calculation we found that $$ Average\ length = E(l(x)) = H(p) = 1.375 $$ This isn't quite as good as when we are not constrained to integer length encodings, but it is the optimal encoding we can get given this restriction.

You may have noticed that entropy seems to be higher when we have a uniform distribution rather than a distribution with probability mass concentrated at various points. I won't prove it here, but a uniform distribution does in fact result in the maximal entropy possible. This fact connects to the interpretation of entropy as a measure of information or surprise. In a probability space, if the the likelihood of any event occurring is equally probable (i.e. uniformly distributed), it is the hardest to predict what event will occur at any given time. Hence, in a sense there is more "surprise" or less certainty regarding the occurrence of events. Conversely, if all probability mass is concentrated on one point, that is, one event occurs with probability equal to 1, then entropy is minimal as we know with certainty which event will occur at all times. Entropy is also an important notion in physics where it is used in relation to the energy of a system

If it's not clear from this post what all of this entropy stuff has to do with machine learning and loss-functions, don't worry, you didn't miss anything. The next post on cross-entropy will try to address this a little more directly, but it's useful to have at least a basic undestanding of entropy before delvign into cross-entropy and its use as a loss function.

The continuation of this post, which will delve into cross-entropy can be found here.
